Precision welded pipe production line for acoustic logging pipes

Short Description:

ZTZG’s quick-change worktable welded pipe production line:
It allows rolls to be pre-assembled onto the quick-change table or bracket on the quick-change shaft.
The entire pipe production line, including the plate forming, sizing, and rough straightening sections, can be equipped with a spare quick-change worktable.

https://www.ztzgsteeltech.com/hydraulic-shaft-quick-change-erw-pipe-mill/

When producing pipes of different sizes, the quick-change worktable that requires replacement can be directly loaded onto the pipe production line, replacing the existing pipe production unit.
This system eliminates the need to disassemble and install rolls during roll replacement, saving significant production time and improving pipe manufacturing efficiency.
This pipe making machine is suitable for pipe manufacturers producing small and medium-diameter welded pipes.


  • Place of Origin: Hebei, China (Mainland)
  • Port: Xingang, Tianjin, Customer Specified
  • Payment: T/T, Cash, Paypal, D/P
  • Certification: ISO, CE, Invention Patent
  • Warranty: 1 Year
  • After-sales Service: Online Technical Support, Engineer On-site Guidance
  • Application: Metallurgy, Construction, Transportation, Vehicle Industries, etc.
  • Product Detail

    PRODUCT MODEL LIST

    Product Tags

    ◈
    Sonic logging pipes are pre-embedded pipes specifically designed for concrete cast-in-place piles. Their core function is to use ultrasonic transmission methods to detect pile integrity, serving as the sole channel for pile quality inspection.
    The sonic logging steel pipe production line is a specialized precision welded pipe production line for bridge pile foundations, tunnel support piles, photovoltaic foundation piles, and other applications requiring non-destructive testing of pile foundations.

    https://www.ztzgsteeltech.com/quick-change-workbench-welding-pipe-equipment-production-line-product/

    This tube-making machine adopts ZTZG’s quick-change worktable technology.

    ZTZG’s quick-change worktable welded pipe production line:
    • It allows rolls to be pre-assembled onto the quick-change table or bracket on the quick-change shaft.
    • The entire pipe production line, including the plate forming, sizing, and rough straightening sections, can be equipped with a spare quick-change worktable.

    https://www.ztzgsteeltech.com/hydraulic-shaft-quick-change-erw-pipe-mill/

    When producing pipes of different sizes, the quick-change worktable that requires replacement can be directly loaded onto the pipe production line, replacing the existing pipe production unit.

    https://www.ztzgsteeltech.com/round-tube-mill-pipe-mill/

    This system eliminates the need to disassemble and install rolls during roll replacement, saving significant production time and improving pipe manufacturing efficiency.

    https://www.ztzgsteeltech.com/quick-change-workbench-welding-pipe-equipment-production-line-product/

    This pipe making machine is suitable for pipe manufacturers producing small and medium-diameter welded pipes.

    Advantages:
    01 Compared to standard welded pipe machine replacement methods, the roll replacement cycle can be shortened by 4/5.
    02 No need to remove flange plate bolts.
    03 Perfectly solves the water backflow problem.
    04 Automatically removes scale and dust during operation.

    Quick-Change Worktable ERW Tube Mill — Common Specifications Production Table
    Application: high-frequency straight-seam (ERW) welded tube lines with quick-change roll stands / worktables; materials Q195/Q235/Q355, cold-rolled and galvanized strip; round, square and rectangular tubes. Quick-change models target small and medium sizes with short changeover times.
    No. Mill Model Round Tube Forming Range (Φ mm) Min. Φ Max. Φ Square Tube Forming Range (mm) Min. Side Max. Side Matching Rectangular Tube Thickness Range (mm) Min. Wall Max. Wall Max Speed (m/min)
    1 ERW20 Φ8–Φ20 8 20 6×6–15×15 6 15 8×12, 10×15 0.3–1.5 0.3 1.5 120
    2 ERW32 Φ10–Φ32 10 32 10×10–25×25 10 25 10×20, 15×25 0.5–2.0 0.5 2 120
    3 ERW50 Φ20–Φ50 20 50 15×15–40×40 15 40 20×30, 25×40 0.8–3.0 0.8 3 120
    4 ERW76 Φ32–Φ76 32 76 25×25–60×60 25 60 30×50, 40×60 1.2–4.0 1.2 4 120
    5 ERW89 Φ42–Φ89 42 89 35×35–70×70 35 70 40×60, 50×70 1.5–4.5 1.5 4.5 110
    6 ERW114 Φ48–Φ114 48 114 40×40–90×90 40 90 50×70, 60×80 1.5–4.5 1.5 4.5 65
    Notes and Supplementary Remarks
    Application Scope ERW tube mills with quick-change roll stand / quick-change worktable structure; covers round, square and rectangular tubes.
    Applicable Materials Q195 / Q235 / Q355, cold-rolled strip and galvanized strip.
    Line Speed Basis The maximum line speeds shown are the upper limits for thin-wall small tubes; heavy-wall and large-size production runs correspondingly slower.
    Finished Length Standard 6–12 m, length tolerance ±3 mm (other lengths by agreement).
    Rectangular Tube Note Not unlimited combinations: sizes are constrained by the forming pass and strip width; new sizes need dedicated quick-change rolls.
    Structure Note Standard quick-change worktable version, unlike conventional fixed-stand mills; large diameters (Φ219 and above) are generally not built with this structure.
